ZE18GU
Mini excavator
- Operating weight
1800 kg - Rated power
11.8 kw - Standard capacity
0.04 m³ - Max. Digging raduis
3910mm - Max. Digging Depth
2316mm - Max. Dumping Height
2429mm
ADVANTAGES
- Standard TOPS/FOPS safety cab
- The customized load-sensitive hydraulic system is adopted to improve the micro-control of the whole machine operation by 10% and the coordination of compound actions by 5%.
- Tailless design, split detachable cab, the whole machine is more flexible and more passable.
Cab
- OPG/TOPS/ROPS safe cab as standard configuration， Effectively protect the safety of the driver.
- It is equipped with luxurious seats with large backrests that can be adjusted fore and aft and in angle, which can reduce driving
- fatigue and make driving more comfortable with the help of wrist rest.
- It is equipped with a 4.3-inch LCD color screen and a brand-new human-computer interactive operating system, which features rich functions and simple and easy use.
- The cab can be quickly disassembled with simple tools. After the cab is disassembled, the overall height of the excavator is less than 1.5m, and the excavator trafficability is better.
- The layout of the tail space is optimized, the real tailless slewing is realized, and it is more suitable for the operation in a narrowspace.
Power system, Hydraulic System
- It is equipped with a Kubota micro-digging-dedicated engine, with a rated power of 11.8kW. It has strong power, meets
- EU5/US4 emission standards, and its high-power and low-noise design is conducive to environmental protection and health.
- It is equipped with a customized load-sensitive hydraulic system, which can sense small changes of loads and adjust flow and pressure at any time to achieve perfect handling performance.
- It can be equipped with crushing pipeline, auxiliary equipment pipeline, hydraulicquick-change pipeline, electric proportional lever, etc., to meet the fittings needs of usersunder different working conditions, such as digging, loading and unloading, crushing,drilling and so on.
Undercarriage
- With a leading structural design, the chassis telescopic beams are made of profile steel, which has higher reliability.
- The traveling motor seat adopts cast steel structure, which greatly reduces the stress level and extends the service life.
- The chassis pipelines are built-in, so the service life of the hose is extended in the harsh working environment.
- The rocker switch can easily realize the extending and retracting of the chassis. With the width adjustable bulldozer blade, it ismore suitable for entering and exiting narrow spaces.
Working equipment (boom, stick, bucket）
- Cast steel structures are adopted in the key bearing parts such as front support, rear support and deflection seat of boom, which have good reliability.
- The boom adopts the advanced hollow large-section box structure, and the high-strength steel plates are matched with the cast steel structures for higher reliability.
- The key parts of the bucket are made of NM400 wear-resistant steel plates, and the service life is 30% longer than that of ordinary materials.
- A large-angle left and right deflection working device is designed, which is really suitable for boundary operation in a narrow space.
- The hinged points of the working device are arranged on one side, which is simple and convenient for filling grease.
